PS180-IRW

2MP Starlight HDCVI IR Bullet Camera HC120-IRW

Features:

  • Starlight
  • 30fps@1080P
  • Switchable output HD and SD
  • Fixed lens of 3.6mm fixed lens
  • IR length 80m
  • IP67 Protection

Download: https://videolineusa.com/wp-content/uploads/2022/10/HC120-.pdf

Camera
Image Sensor 1/2.8 inch CMOS
Effective Pixels 1920 (H) × 1080 (V), 2MP
Electronic Shutter Speed PAL:1/25s–1/100000s NTSC:1/30s–1/100000s
Minimum Illumination 0.005Lux/F1.6, 30IRE, 0Lux IR on
IR Distance Distance up to 80 m (262.46 ft)
IR On/Off Control Auto; manual
IR LEDs Number 2
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 3.6 mm; 6 mm; 8 mm
Max. Aperture F1.6
Angle of View 3.6 mm: 103.6°×86.9°×46.3° (diagonal × horizontal × vertical) 6 mm: 60.3°×52.9°×30.3° (diagonal × horizontal × vertical) 46.7°×40.5°×22.4° (diagonal × horizontal × vertical)
Iris Type Fixed iris
Min Photographic Distance 1.2 m/2.4 m/3.3 m (3.93 ft/7.87 ft/10.82 ft)
Video
Video Frame Rate CVI: 1080P@25fps/30fps; 720P@25fps/30fps; 720@50fps/60fps; AHD: 1080P@25fps/30fps; 720P@25fps/30fps; TVI: 1080P@25fps/30fps; 720P@25fps/30fps; 720@50fps/60fps; CVBS: 960H
Resolution 1080P (1920 × 1080); 720P (1280 × 720); 960H (960 × 576/960 × 480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Electronic Defog Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Network
Ethernet RJ-45 (10/100Base-T)
Certifications CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Dimensions 240.7 mm × 90.7 mm × 90.4 mm (9.48" × 3.57" × 3.56")
Net Weight 410 g (0.90 lb)
Port
Video Port Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12V±30% DC
Power Consumption Max 4.9W (12V DC, IR on)
